Name: PavementAssessment

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This layer holds the data collected and updated by the Public Works Department, Roads Division on the quality and condition of the Village of Wellington maintained streets via Esri Field Maps. Each street is graded every three years and given a score out of 100 from numerous factors such as cracking, corrugations, raveling, rutting, etc. This information collected from the field can be found in the Facilities/Streets Enterprise dataset. Also located on the Street Maintenance web application to be viewed internally. When the assessment is completed, a report is created. The MXD needed to create this report is located here Y:\Data\Requests\Public Works\Roads\Asphalt Assessment. When report is complete, create new year folder for the document in the same location as the MXD. </SPAN></P></DIV></DIV></DIV>

Copyright Text: Village of Wellington GIS; Public Works Department; Roads Division

Default Visibility: true

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 856131.8832112625
YMin: 814965.9390064478
XMax: 929344.8017457612
YMax: 855952.1628081128
Spatial Reference: 2881  (2881)  VCSWkid(105703)  LatestVCSWkid(6360)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: YEARASSESSED
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 1
Default Label: <all other values>
UniqueValueInfos:
• Value: 2020
  Label: 2020
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 3
• Value: 2021
  Label: 2021
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 170, 0, 255]
  Width: 3
• Value: 2022
  Label: 2022
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 112, 255, 255]
  Width: 3
• Value: 2023
  Label: 2023
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [85, 255, 0, 255]
  Width: 3
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FULLNAME ( type: esriFieldTypeString, alias: Full Road Name, length: 255 )
• OWNEDBY ( type: esriFieldTypeSmallInteger, alias: Owned By , Coded Values: [1: Our Agency] , [-1: Private] , [-2: Other] , ...4 more... )
• MAINTBY ( type: esriFieldTypeSmallInteger, alias: Managed By , Coded Values: [1: Our Agency] , [-1: Private] , [-2: Other] , ...4 more... )
• PREFIX ( type: esriFieldTypeString, alias: Prefix, length: 2 )
• NAME ( type: esriFieldTypeString, alias: Name, length: 80 )
• TYPE ( type: esriFieldTypeString, alias: Type, length: 6 )
• SUFFIX ( type: esriFieldTypeString, alias: Suffix, length: 2 )
• FROMLEFT ( type: esriFieldTypeDouble, alias: From Left )
• TOLEFT ( type: esriFieldTypeDouble, alias: To Left )
• FROMRIGHT ( type: esriFieldTypeDouble, alias: From Right )
• TORIGHT ( type: esriFieldTypeDouble, alias: To Right )
• RESP_AUTH ( type: esriFieldTypeString, alias: Responsible Authority, length: 10 , Coded Values: [WELL: Wellington] , [RPB: Royal Palm Beach] , [LW: Lake Worth] , ...7 more... )
• FUNC_CLASS ( type: esriFieldTypeString, alias: Function Class, length: 50 )
• SPEED_LIMIT ( type: esriFieldTypeDouble, alias: Speed Limit , Coded Values: [25: 25] , [30: 30] , [32: 32] , ...8 more... )
• LANES ( type: esriFieldTypeDouble, alias: Lanes , Coded Values: [2: 2] , [3: 3] , [4: 4] , ...4 more... )
• WELL_TYPE ( type: esriFieldTypeString, alias: Priority Type, length: 20 , Coded Values: [Residential: Residential] , [Florida Turnpike: Floridas Turnpike] , [Major: Major Road] , ...3 more... )
• SURFACE_TYPE ( type: esriFieldTypeString, alias: Surface Type, length: 5 , Coded Values: [ASPL: Asphalt] , [ASMIL: Asphalt Millings] , [SRCK: Shell Rock] , ...3 more... )
• YEARASSESSED ( type: esriFieldTypeInteger, alias: Year Assessed , Coded Values: [2017: 2017] , [2018: 2018] , [2019: 2019] , ...6 more... )
• FISCALYRRESURFACED ( type: esriFieldTypeString, alias: Fiscal Year Resurfaced, length: 9 , Coded Values: [1998_1999: 1998/1999] , [1999_2000: 1999/2000] , [2000_2001: 2000/2001] , ...26 more... )
• WIDTH ( type: esriFieldTypeSmallInteger, alias: Width )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• TRANSVERSE ( type: esriFieldTypeSmallInteger, alias: Transverse Cracks , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• LONGITUDINAL ( type: esriFieldTypeSmallInteger, alias: Longitudinal Cracks , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• ALLIGATOR ( type: esriFieldTypeSmallInteger, alias: Alligator Cracks , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• SHRINKAGE ( type: esriFieldTypeSmallInteger, alias: Shrinkage Cracks , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• RUTTING ( type: esriFieldTypeSmallInteger, alias: Rutting , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• CORRUGATIONS ( type: esriFieldTypeSmallInteger, alias: Corrugations , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• RAVELING ( type: esriFieldTypeSmallInteger, alias: Raveling Raveling Raveling Raveling , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• SHOVING_PUSHING ( type: esriFieldTypeSmallInteger, alias: Shoving or Pushing , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• POTHOLES ( type: esriFieldTypeSmallInteger, alias: Pot Holes , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• EXCESSASPHALT ( type: esriFieldTypeSmallInteger, alias: Excess Asphalt , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• POLISHEDAGGREGATE ( type: esriFieldTypeSmallInteger, alias: Polished Aggregate , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...3 more... )
• DEFICIENTDRAINAGE ( type: esriFieldTypeSmallInteger, alias: Deficient Drainage , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• OVERALL ( type: esriFieldTypeSmallInteger, alias: Overall Riding Quality , Coded Values: [0: 0] , [1: 1] , [2: 2] , ...8 more... )
• DEFECTS_SUM ( type: esriFieldTypeSmallInteger, alias: Sum of Defects )
• CONDITION_RATING ( type: esriFieldTypeSmallInteger, alias: Condition Rating )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
